S-Series

Flanges | Product Codes | Mitre Cuts | Multi-Bracket | Downloads | Products | NBS


Roller Blind Concealment

Aluminium profiles for concealment of Roller Blinds

Application

Concealment for Roller Blinds

Max Sizes

Profile Width: 6m*

*Sections of profile can be attached with splice pins.

‣

Flanges

S (Standard Plastering Flange)


N (No Flange)

‣

Product Codes

Blindspace product codes are made up of three variables.

1st: The name of the type of Blindspace, S (S-Series) or C (C-Series)

2nd: The size of profile, eg. 100x100

3rd: The names of the two flanges to be used, S (standard) or N (no flange).

Example product code: S100x100SN (s-series Blindspace, 100mm by 100mm, one side with standard flange one side with no flange)

‣

Mitre Cuts

Angled Edges for Blindspace.

Custom angled Blindspace for the neatest finishes.

Note: A mitre can only be cut on one end of a continuous profile. For two mitres on one length you can use a joiner kit.

If you require a continuous cover plate, you can order an oversize one separately and cut it down on site.

Blindspace Mitre Options.pdf186.8 KB

Evolve Multi-Bracket

A new Blindspace Bracket for Evolve and Evolve Zero.

  • Adjustable Positioning - more control over where your blind falls and how far the hembar rolls up.
  • Grub Screw Fixing - no need to drill into the ceiling.

⬇️See Product Downloads Below ⬇️

Downloads

‣

Technical Drawings

‣
PDF

Evolve & Evolve Zero

Evolve S100x100381.3KB
Evolve S130x130390.0KB

Sirios & Solaris

Sirios S100x100377.6KB
Sirios S130x130380.1KB
‣
CAD

Evolve & Evolve Zero

Evolve S100x100196.9KB
Evolve S130x130199.1KB

Sirios & Solaris

Sirios S100x100195.1KB
Sirios S130x130194.4KB
‣
Evolve Multi-Bracket

PDF

S100x100 - Luxury 35510.8KB
S100x100 - Ellipse 43510.2KB
S130x130 - Luxury 35677.8KB
S130x130 - Ellipse 43676.9KB

CAD

S100x100 - Luxury 351136.2KB
S100x100 - Ellipse 431135.8KB
S130x130 - Luxury 351206.8KB
S130x130 - Ellipse 431201.4KB
‣
Mitre Cuts
Blindspace Mitre Options.pdf186.8 KB
‣

Fitting Instructions

Headbox3.5 MB
Headbox & Side Channels4.3 MB
icon
The Data Centre - All Files

S-Series Works With
